Widely used in paint, paint, cosmetics, ink, pulp, food, oil, starch, solvent adhesive, latex, biochemical products and other industries.
Technical paramater:
Control / display mode: 5-inch color touch screen
speed(r/min): 0.1–200 infinitely variable speed, a total of 2000 speed options
measuring range:
Rotor 1-4: 10–6M mPa.s
ULR: 0.3-6K
Rotor 18: 1.5 – 300K
Rotor 25: 240 – 4.8M
Rotor 31: 15 – 300K
Rotor 34: 30 – 600K
rotor:
L1 – L4 (Standard)
Enhanced ultra-low viscosity adapter ULR (optional)
Small sample adapters (rotors 18,25,31,34)(optional))
Sample dosage:
Rotor 1- 4: 300 – 400ml
ULR: 21ml
Rotor 18: 7ml
Rotor 25: 9ml
Rotor 31: 10.5ml
Rotor 34: 11ml
K = 1000; M = 1000000
measurement error: ±1% (Newtonian liquid)
repetitive error: ±0.5% (Newtonian liquid)
Show shear response /shear rate: standard configuration
Timing function: standard configuration
Real-time display Viscosity curve:
Temperature-time curve
Viscosity-time curve (The rheological curves of shear rate and viscosity can be displayed by optional data processing software)
kinematic viscosity: Density of samples to be entered
Temperature measurement function: Standard temperature probe interface (optional temperature probe)
Automatic Scanning Function: Automatically scan and recommend the preferred combination of rotor and rotation speed
Maximum measurement range: Automatic display of selected combinations of rotor and rotation speed. Measurable viscosity range
Self-built Measuring Procedures: Up to 30 groups (including rotor, speed, temperature, time, etc.)
Preservation of measurements: Up to 30 sets of data (including viscosity, temperature, rotor, speed, shear rate, shear stress, time, density, kinematic viscosity, etc.)
put a seal on: Data, curve can be printed (standard print interface, need to buy printer)
data output interface:
USB: can insert U disk and copy data directly
RS232: Connect Computer
thermostatic components: Selections (including various viscometer special thermostatic tank, thermostatic cup, temperature control device, heating furnace)
working power supply: Wide voltage operation (110 V/60 Hz or 220 V/50 Hz)
outline dimension: 300 × 300 × 450(mm)
Main features:
Using ARM technology, built-in Linux system. The operation interface is simple and clear, and the viscosity test is carried out quickly and conveniently through the creation of test program and data analysis;
The viscosity measurement value is accurate: each measuring range uses the computer automatic calibration, the precision is high, the error is small;
2 Rich display: in addition to viscosity (dynamic viscosity and kinematic viscosity), there are temperature, shear rate, shear stress, measured value as a percentage of full range value (graphic display), range overflow alarm, automatic scanning, the measurement range under current rotor speed combination, date, time, etc. The kinematic viscosity can be displayed in the case of known density to meet the different measurement requirements of users;
4 Complete function: can measure time, self-built 30 sets of test program, access 30 sets of measurement data, real-time display viscosity curve, print data and curve;
5 Front level instrument: level adjustment is intuitive and convenient;
6 stepless speed regulation: RV1T series :0.3-100 rpm ,998 rpm
RV2T series :0.1-200 rpm ,2000 rpm
Show the curve of shear rate to viscosity: can set the range of shear rate, real-time display on the computer; can also
A curve showing time versus viscosity
Standard USB interface: insert U disk to copy data directly
Optional Pt100 temperature probe: temperature range from -20 to 300℃, temperature measurement accuracy 0.1℃;
10 Rich optional accessories: Viscometer dedicated thermostatic bath, thermostat cup, printer, standard viscosity sample (standard silicone oil)
etc;
Chinese and English operating system (set before leaving the factory).
the torque of the filament, the shape of the rotor, the size of the rotational speed, and the range of viscosity measurement are the same as the imported viscometer of the same type. the measured viscosity and other data are well comparable with the imported similar instruments.
