Application
★ The effectiveness and efficiency of surfactants were evaluated by measuring critical micelle concentration
★ Wettability of tablets, pharmaceutical active ingredients and excipients
★ Wettability of paint and coatings
Oil aging degree detection
★ Coating wettability and adhesion
★ Cosmetic development
★ Study on ink wetting characteristics
Specification
Test method*: Platinum plate method, platinum ring method
Surface tension test range: 0－2000mN/m
Accuracy of surface tension: 0.1mN/m
Liquid density range: 0－3.000g/cm3 N/A
Density accuracy: 0.001g/cm3 N/A
Operating mode: Automatic lifting and automatic measurement of sample table
Lifting speed: 0－300mm/min can be adjusted arbitrarily
Display mode: 7 inch touch screen data direct reading
Data mode: Supports data storage, viewing, and printing
Measuring time: Routine within 60 seconds
Data output: RS232(printer) or USB
Data software: ST Flash software is standard
Dimension: 47*24.5*47.5 cm Length * width * height
Net weight: 18kg
Power supply: 110V or220V, 50W
Platinum ring size: wire radius of 0.185mm, ring radius of 9.55mm, ring circumference of 60mm.
* Note: plate/ring test method, need to indicate when ordering, standard configuration of one of the two, the budget is enough to suggest that both plate and ring configuration.
** Note: The printer is not included in the standard configuration, it is optional according to the demand, the measurement of liquid density need to buy a standard volume.
