Vibration measurement range
o Acceleration: 0.1 m/s2~392.0 m/s2 (Peak) (Standard configuration: 0.1mm/s2- 205.6mm/s2)
o Rate: 0.1 mm/s~800.0 mm/s (Valid values) (Standard configuration : 0.1mm/s-400.0mm/s)
o A move: 0.001 mm~18.1 mm (Peak) (Standard configuration : 0.001mm/s-9.0mm)
Frequency range:
10Hz~200Hz
10Hz~500Hz
10Hz~1kHz
10Hz~10kHz
Allowable vibration measurement error: ±5%
Analysis frequency interval: 0.25Hz
Speed measurement range: 30~300000 rpm (5~5kHz)
Permissible error in speed measurement: ± (0.05% + 1)
Speed measurement distance: 0.15~1m
Temperature range: 0℃～40℃
Humidity range: ≤80％RH
Display: TFT Color LCD screen，320 × 240pixel
Storage capacity: 8,000 data sets and 100 spectral images (100 measurement points)
Upper computer software: Optional communication Mini USB
External dimension: 212 × 80 × 35
Print function: Embedded thermal printer, on – call
Battery life: The 1500mAh high performance lithium-ion Rechargeable battery: lasts 50 hours
Machine weight: 320g
