CCECB0311
Electrode distance: 3.0 m
Initial stretch length: 4.5 m
Length EL 1-24: 69.0 m
Cable total length: 73.3 m
Monitored profile length (2 cables): 141.0 m
Current Injection Circuit
Number of channels: 48 electrodes
Current range: 0.001 – 0.4 A
Current resolution: 120 µA
Current measurement resolution: 1 µA
Accuracy: < 60 µA
Electrode voltage measurement: automatic range switching
Input impedance: 1.6 × 10⁹ Ω
Noise filtering: automatic 50 / 60 Hz
0.47 V range: Resolution: 1 µV; Accuracy: 70 µV
4.7 V range: Resolution: 10 µV; Accuracy: 700 µV
Range: -55 to +150 °C
Resolution: 0.1 °C
Accuracy: ±0.3 °C
Power supply: 115 – 230 V AC, 50/60 Hz
Backup battery: 40 Ah
Solar panel: 50 W
Power consumption: 150 mW (low power mode, modem off); 5 W (low power mode, modem on); 7 W (standby); 115 W (maximum during measurement)
Maximum operating time: ~10 days (1 measurement/day, ~40 minutes per measurement)
Enclosure dimensions: 730 × 530 × 270 mm
Enclosure weight (without battery): 13.5 kg
Protection rating: IP66
Nominal voltage: 300/500 V
Test voltage: 4000 V
Operating temperature: -50 to +80 °C
Environmental resistance: chemicals, UV, ozone, industrial
Material: Stainless steel AISI 316
Plate: 230 × 128 mm, thickness 1 mm
Rod: length 400 mm, Ø10 mm
Automatic voltage disconnection in case of fault: ~4 seconds
