Capacity: 50kg
Material: Stainless Steel
Rated Output: (1.5 ± 10)% * mV / V
Zero Balance: ± 2% * F .S.
Non-linearity: ± 0.1% * F .S.
Hysteresis: ± 0.1% * F .S.
Repeatability: ±0.1% * F * 0.5
Creep (30min): (± 0.05)% * F .S
Temp. Effect on Output: ±0.05% / 10 deg * C
Temp. Effect on Zero: (± 0.05)% * 1 F.S./10°C
Input Impedance: 350 ± 10 * Omega
Output Impedance: 350 ± 5 * Omega
Insulation: >= 5000M*Omega / 100 * VDC
Recommended Excitation: 3-5V
Operating Temp. Range: - 20 - 80 deg * C
Compensated Temp. Range: - 10 - 60 deg * C
Safe Overload: 150%
Maximum Overload: 200%
Cable Specifications: Φ2 * 3m
Protection Class: IP5650
