General
Memory: 32,356 readings
Reading Rate: 1 reading every 0.25 seconds up to 1 reading every 24 hours
Baud Rate: 125000
Battery Life: 2 years typical (1 minute reading rate); User Replaceable Battery
Material: Body: 316 Stainless Steel, Radel ; Probe: PFA Insulated Cable with Stainless Steel Tip
Dimensions (Body): 2.95 in x 0.97 in x 0.97 in (75 mm x 24.6 mm x 24.6 mm)
Dimensions (Probe): HiTemp140-FPST-6: 6 in x 0.13 in (152 mm x 3.2 mm)
Key Ring End Cap: Key ring replaces standard bottom; Thru-hole: 0.150"
IP Rating: IP68
Submersible: Yes
Operating Environment:
- -40 °C to +140 °C (-40 °F to +284 °F) Body of Logger Cannot Exceed 140 °C
- 0 %RH to 100 %RH, 0 PSIA to 100 PSIA
- With Thermal Shield: -200 °C to +250 °C (-328 °F to +482 °F)
Required Interface Package: IFC400 or IFC406
Approvals: CE
Weight: 0.1875 LBS
Temperature:
Temperature Sensor: Flexible RTD Probe
Temperature Resolution: 0.01 °C (0.018 °F)
Temperature Calibrated Accuracy:
- ±0.1 °C from +20 °C to +140 °C
- ±0.3 °C from -20 °C to +19.99 °C
- ±0.4 °C from -40 °C to -20.01 °C
Probe Temperature Range: -200 °C to +260 °C (-328 °F to +500 °F) (Body of Logger Cannot Exceed 140 °C)
