Mark-10 F1505-EM Digital Force Testers (1500 lbF[6.7 kN])

Load capacity: 1500 lbF[6.7 kN]

Maximum travel: 32 in[813 mm]

Standard speed range: 0.5 - 24 in/min[10 - 600 mm/min]

Optional speed range: 0.001 - 70 in/min[0.02 - 1800 mm/min]

Peak sampling rate: 5.000 Hz

Data acquisition rate: 100 Hz (requires Graphing & Reporting option)

Speed accuracy: ±0.2% of setting, virtually no variation with load

Position accuracy: ±0.006 in [0.15 mm], at any load or position

Distance resolution: 0.001 in [0.02 mm]

Limit switch repeatability: ±0.001 in [0.03 mm]

Overload protection: Motor stops at 120% of full scale of the force sensor

Power: Universal input 100-240 VAC, 50/60 Hz, 450W

Fuse type: 4A, 3AG, SLO BLO

Weight: 197 lb[89 kg]
