Width: 5.9 mm
Height: 8.7 mm
Length: 5.9 mm
LED Size: T-1 3/4 (5 mm)
Lens Color: Colorless
Lens Shape: Dome
Power Rating: 72 mW
Configuration: Common Anode
Viewing Angle: 70 deg
Mounting Style: Through Hole
Lens Dimensions: 5 mm
Peak Wavelength: 650 nm, 573 nm
Lens Transparency: Diffused
Illumination Color: Red, Yellow-Green
Luminous Intensity: 20 mcd
Moisture Sensitive: Yes
If - Forward Current: 20 mA
Vf - Forward Voltage: 1.9 V
Wavelength/Color Temperature: 639 nm, 570 nm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
