MATRIX MPS-3605LP Single Channel DC Power Supply (36V, 5A, 180W)
Manufacturer: MATRIX Model: MPS-3605LP - Contact
Rated input voltage: AC220V/110V±10%
Rated output voltage: 0~36V
Rated output current: 0~5A
Rated output power: 180W
Load regulation rate: Voltage 0.05%+8mV, Current 0.1%+5mA
Line regulation: Voltage 0.05%+8mV, Current 0.1%+5mA
Setting value resolution: Voltage 10mV, Current 1mA
Readback value resolution: Voltage 10mV, Current 1mA
Setting accuracy (25°C±5°C): Voltage ≤0.1%+2digits, Current ≤0.2%+3 digits
Readback accuracy (25°C±5°C): Voltage ≤0.1%+2digits, Current ≤0.2%+3 digits
Ripple: Voltage 1.5 mVrms, Current 3mArms
Temperature coefficient: Operation 300ppm, Storage 300ppm
Instrument size (WxHxD): 215x95x300 mm
Net weight: 6.7kg
Gross weight: 7.8kg
Datasheet
Catalog
Function
• List programme output function
• Save last time output data and state
• External trigger function
• Pass/fall signal output function Nine sets of voltage and current storage and recall function, convenient and quick
• Intelligent temperature control fan, extremely practical
• The knob adopts the code switch, which is convenient to use and has the function of preventing misadjustment
Application:
1.Routine test and maintenance of production line;
2.Laboratory and Research Institute;
3.Simulation test of new energy vehicles;
4. Automation equipment integration test
