Maxim Integrated MAX6381XR29D3+T Voltage Supervisory SC70/ DFN, Single/Dual Low-Voltage, Low-Power P Reset Circuits

Width: 1.35 mm

Height: 1 mm

Length: 2.2 mm

Accuracy: 2.5 %

Output Type: Active Low, Push-Pull

Unit Weight: 4.768 g

Manual Reset: No Manual Reset

Mounting Style: SMD/SMT

Watchdog Timers: No Watchdog

Reset Delay Time: 280 ms

Threshold Voltage: 2.93 V

Chip Enable Signals: No Chip Enable

Power Fail Detection: No

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 1 V

Overvoltage Threshold: 3 V

Pd - Power Dissipation: 235 mW

Undervoltage Threshold: 2.85 V

Battery Backup Switching: No Backup

Operating Supply Current: 7 uA

Number of Inputs Monitored: 1 Input

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
