Width: 5 mm
Height: 1 mm
Length: 6 mm
Function: With light load PFM, enable, Power Good, power sequencing, UVLO, built-in 3.3/5V LDO, adjustable soft start, adjustable current limit, internal compensation
Shutdown: No Shutdown
Topology: Buck
Input Voltage: 3 V to 22 V
Mounting Style: SMD/SMT
Output Current: 15 A
Output Voltage: 600 mV to 18 V
Development Kit: XR76117EVB
Load Regulation: 0.1 %
Number of Outputs: 1 Output
Quiescent Current: 800 uA
Moisture Sensitive: Yes
Input Voltage - Max: 22 V
Input Voltage - Min: 3 V
Switching Frequency: 200 kHz to 1 MHz
Supply Voltage - Min: 3 V
Pd - Power Dissipation: 3.8 W
Operating Supply Current: 17 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
