Gain: 2.7 dBi, 3.2 dBi, 3.4 dBi, 5.1 dBi, 5.3 dBi
VSWR: 1.3:1, 1.4:1, 1.6:1, 1.8:1, 2.7:1
Style: Square
Width: 74 mm
Height: 25.6 mm
Length: 80 mm
IP Rating: IP67, IP69
Impedance: 50 Ohms
Cable Type: 2 M D302 x 2, 2 M D100
Application: IoT Applications, Telematic, Navigation, Satellite Communications, Cellular Applications
Cable Length: 2 m
Polarization: RHCP
Power Rating: 25 W
Mounting Style: Direct / Permanent Mount
Frequency Range: 698 MHz to 960 MHz, 1575.42 MHz, 1598 MHz to 1606 MHz, 1710 MHz to 2170 MHz, 2410 MHz to 2490 MHz, 4920 MHz to 5925 MHz
Number of Bands: 7 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2600 MHz, 2400 MHz, 5000 MHz, 1575 MHz, 1602 MHz
Mechanical Style: Module
Maximum Frequency: 5.925 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: Galileo, GLONASS, GPS, QZSS
Protocol - WiFi - 802.11: LoRaWAN, Sigfox, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
