Gain: 3.8 dBi, 2.9 dBi, 4.4 dBi
VSWR: 3.5, 2.5, 2.5
Style: I-Bar
Width: 30.1 mm
Height: 6.7 mm
Length: 105.1 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 1 M RG174/U
Application: Automotive, Fleet Tracking, IoT, Telematics
Unit Weight: 40 g
Cable Length: 1 m
Mounting Style: Adhesive Mount
Number of Bands: 3 Band
Center Frequency: 829 MHz, 1.94 GHz, 2.5 GHz
Mechanical Style: Module
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID, IoT
Antenna Connector Type: SMA / FAKRA
Protocol - WiFi - 802.11: WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS
