Width: 177.8 mm (7 in)
Height: 63.5 mm (2.5 in)
Length: 278 mm (10.945 in)
Industry: Industrial
Approvals: EAC TP TC004, EN62368-1, Ul62368-1
Compliance: EAC TP TC004, EN62368-1, Ul62368-1
Efficiency: 93 %
Unit Weight: 4 kg
Output Power: 3 kW
Input Voltage: 180 VAC to 264 VAC, 254 VDC to 370 VDC
Mounting Style: Chassis
Input Frequency: 50 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Power - Forced Air: 3 kW
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 7.5 A
Output Voltage-Channel 1: 400 VDC
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 20 C
