Instrument applicable environment: Temperature: 0~40℃; Usage altitude: within an altitude of 2Km use; Relative humidity: 40~80%
Battery voltage measurement range: 0~80.000V, resolution 0.001V
Overcurrent measurement range: 0~20.000A, resolution 0.001A
Internal resistance measurement range: 5mΩ~999mΩ, resolution 0.1mΩ
Resistance identification range: 0.1~999.9KΩ, with a minimum resolution 0.1KΩ
Capacity measurement range: 200mAh~100.0Ah, with a minimum resolution 0.1mAh
Static testing speed: 1.1~2 seconds
Capacity test time (1C charge/discharge): 3~4 hours
Voltage measurement accuracy: ±(result ×0.5% +3mV)
Current measurement accuracy: ±(result ×0.5% +5mA)
Internal resistance accuracy: ±(result ×1% +1mΩ)
Resistance identification accuracy: 10KΩ ±1%
Battery capacity accuracy: 10Ah ±2%
Output maximum voltage: 60V
Output maximum current: 5A
Maximum output power: 200W
Maximum discharge voltage: 60V
Maximum discharge current: 10A
Maximum power: 200W
Ripple voltage: <20mV
Load adjustment rate: <10%
Response time: 1S
