Tension and Compression
Measurement range: 0.55lbf/ 2.5N/ 0.25kgf
Resolution: 1:50,000 eg. VFG 500 when measuring in newtons has a resolution of 0.01 N
Accuracy: ±0.1 % of full scale*
eg. VFG 500 has a full-scale capacity of 500 so is accurate to ± 0.5 N at any point between 0 - 500 N
Units of measurement: N, N, kN, gf, kgf, ozf, lbf
Sampling Rate: 5,000,000 Hz
Overload Rating: 150% of full scale
Storage:
On-board/built-in memory: 8 MB (approx. 500 stored readings)
Expandable memory: Up to 32 GB (via SDHC card)
Dimensions
*As the device is used in varying environmental conditions, the uncertainty of measurement could be as much as 0.1% of full scale.
Width: 72 mm
Height: 205 mm
Depth: 42 mm
Weight: 740g
