Measurement range:0.1 μΩ - 1.999 Ω
Resolution:0.1 μΩ
Noise rejection:Differential 100 mV @ 50-60 Hz on test leads
DC output:Smooth DC
IP rating:IP54 Open / IP65 Closed
Operating temperature range:-4°F up to +122°F (-20°C up to +50°C)
Storage temperature range:-22°F up to +158°F (-30°C up to +70°C)
Humidity:<85% R.H. non-condensing
Battery life:200 single 100 A tests or up to 2x 10 minutes continuous 100 A output
Battery type:User replaceable Li-ion battery pack
Battery charge time:Full charge in 2.5 Hrs from flat
Maximum output voltage:2 V (battery), 3 V (a.c.)
EMC:IEC61326-1
Safety:IEC61010
CAT IV 600 VAC / 500 VDC up to 2000 m
CAT IV 300 V up to 4000 m
Dimensions:16 x 12 x 8 in. (400 x 300 x 200 mm)
Weight:Mains only: 15.4 lb (7.0 kg)
With battery: 17.4 (7.9 kg)
ACCESSORIES INCLUDES:
- 1004-448: DLRO100 CAT IV 600V std LEAD SET 5M.
- 1005-634: LEAD SET HIGH CURRENT 200A KELVIN
- 1005-622: MCPD 100L - DC CURRENT PROBE
