Viewing Head: Siedentopf binocular, 30° inclined
Interpupillary Distance: 47–76 mm
Eyepieces: EWF 10x/20 mm
Objectives: Plan PLi 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25 oil-immersion DIN IOS
Fungus Protection: All optical parts treated
Nosepiece: Revolving quadruple reversed nosepiece on ball-bearings
Stage: 228.6 × 140 mm
Mechanical Stage: Integrated 79 × 52 mm
Condenser: Height adjustable Abbe condenser, N.A. 1.25
Focusing Adjustment: Coaxial coarse and fine; 2 µm precision; 20 mm travel; friction adjustment
Protection: Rack-stop
Illumination: NeoLED™ Köhler 3W, intensity adjustable
Power Supply: Internal 100–240V
iCare Sensor: Automatic illumination shut-off when user steps away
CSS – Cable Storage System: Rear cable storage; includes power cord, 500 mA 250V fuse, dust cover
Filters: Unmounted blue and green filters, 44.0 mm
Filter Holder: 44.8 mm
Trinocular Tube: 23.2 mm inner diameter; 3 mm Allen key to attach; 2.4 mm Allen key to rotate
Tension Adjustment: “C” wrench
Immersion Oil: Supplied for 100x objective
