VIEWING HEADS
Trinocular with Siedentopf 30° inclined tubes. Interpupillary distance 47-76 mm with diopter adjustment on both eyepieces
EYEPIECES
EWF10x/20 mm
OBJECTIVES
Plan PLi 4x/0.10, 10x/0.25, S40x/0.65, S100x/1.25 oil-immersion DIN IOS objectives
FUNGUS PROTECTION
All optical parts are anti-fungus treated.
NOSEPIECE
Revolving quadruple reversed nosepiece on ball-bearings that is factory centered.
STAGE
228.6mm x 140 mm rackless stage equipped with integrated 79 x 52 mm mechanical stage
CONDENSER
In height adjustable Abbe N.A. 1.25 condenser with opening for optional sliders
FOCUSING ADJUSTMENT
Coaxial coarse and fine adjustments, 2 µm precision, 20 mm travel range. Rack-stop for protection of slides and objectives. Friction adjustment
ILLUMINATION
Diascopic intensity adjustable 3W NeoLED™ Köhler illumination with internal 100-240V power supply. Auto Voltage Sensing Power Supply
iCARE SENSOR
The unique Meiji Techno MT-61 iCare Sensor is developed to avoid unnecessary loss of energy. The illumination of the microscope automatically switches off when the microscopist steps away from his position
CSS - CABLE STORAGE SYSTEM
The Cable Storage System of the MT-61 allows the user to practically insert the power cable into the backside of the instrument, which enables easy storage, Delivered with power cord, 500 mA 250V spare fuse and dust cover
