Volume: 108 liters
Interior dimensions: 560W x 480H x 400D mm
Exterior dimensions: 745W x 1233H x 585D mm
Stainless steel grid: 2
Max. number of grids: 5
Max. loading per grids: 20 kg
Max. loading of chamber: 150 kg
Working temperature range without humidity: -10 to 60°C (not suitable for long-term storing at sub-zero temperatures. During permanent operation, the glass door may ice over)
Working temperature range with humidity: 10 – 60°C
Setting temperature range: -10 to 60°C
Setting accuracy: 0.1°C
2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring, taking over functions in case of an error
Setting range humidity: 10 – 80% rh
Setting accuracy: 0.5% rh
Humidity supply with distilled water from external tank by self-priming pump
Humidification by hot steam generator
Active humidifying and de-humidifying adjustable from 10-80 % rh with digital display of relative humidity - resolution of display 0.1 %, setting accuracy 0.5 %
ControlCOCKPIT:TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour displays.
Adjustable parameters: temperature (Celsius or Fahrenheit), fan speed, programme time, time zones
Language setting: German, English, Spanish, French, Polish, Czech, Hungarian
Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
Function setpointWAIT: the process time does not start until the set temperature is reached
Adjustment of three calibration values for temperature and additional appliance specific parameters directly at the ControlCOCKPIT
Fan: forced air circulation in working chamber adjustable from 10 to 100 % in 10 % steps
Documentation: programme stored in case of power failure
Programming: AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port
Safety
+ Temperature control: mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 10°C above nominal temperature
+ Temperature control: over- and undertemperature monitor TWW, protection class 3.3 or adjustable temperature limiter TWB, protection class 2, selectable on display
+ AutoSAFETY: additionally integrated over- and undertemperature protection "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature, compressor in case of undertemperature
+ Autodiagnostic system: integral fault diagnostics for temperature and humidity control
+ Alarm: visual and acoustic
Cooling: Cooling compressor with climate-neutral refrigerant CO2 (R744), GWP1
Air jacket heating system for gentle all-around heating
No drying-up of the load caused by the cooling device due to separation of thermal jacket from interior
Highly efficient automatic defrosting system
Door: inner glass doors
Doors: outside stainless steel, fully insulated
Structured stainless steel housing, scratch-resistant, robust and durable; rear of zinc-plated steel
Stainless steel interior
Installation: on lockable castors
HeatBALANCE function for application specific adjustment of heat output distribution (balance) between the upper and lower heating groups in an adjustment range between -50 % and +50 %
ControlCOCKPIT with USB port for uploading programmes, reading out protocol logs, activating the User-ID function
Displaying of already logged protocol data on the ControlCOCKPIT (max 10,000 values correspond to approx. 1 week)
Internal data logger with a storage capacity of at least 10 years
Ambient temperature: 15°C to 28°C (up to 34°C with limited temperature range)
Humidity: max. 70% rh, non-condensing
Altitude of installation: max. 2000 m above sea level
Voltage: 230 V, 50 Hz
Electrical load: 1350 W
Accessories:
+ Calibration certificate: standard values 10°C and 37°C, 60% rh at 30°C
+ 2 stainless steel grids
+ Water tank including connection hose
+ Manual
