Temperature
- Setting temperature range: 0 to +70°C
- Working temperature range with light: +10 to +40°C
- Working temperature range without light: from 0 (at least 20 below ambient temperature) to +70°C
- Setting accuracy temperature: 0.1°C
- Temperature sensor: 2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring, taking over functions in case of an error
Control technology
- ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour displays.
- Language setting: German, English, Spanish, French, Polish, Czech, Hungarian
- Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
- Function HeatBALANCE: adapting the distribution of the heating performance of the upper and lower heating circuit from -50 % to +50 %
- Function SetpointWAIT: the process time does not start until the set temperature is reached
- Calibration: three freely selectable temperature values
- Adjustable parameters: temperature (Celsius or Fahrenheit), programme time, time zones, summertime/wintertime
Communication
- Documentation: programme stored in case of power failure
- Programming: AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port
Standard equipment
- Works calibration certificate: for +10°C, +25°C and +40°C
- Door: fully insulated stainless steel door with 2-point locking (compression door lock)
- Internals: 2 stainless steel grid(s), electropolished
- Door: inner glass door
Stainless steel interior
- Dimensions: w(A) x h(B) x d(C): 1040 x 1200 x 600 mm (d less 32 mm for fan - Peltier)
- Volume: 749L
- Max. number of internals: 14
- Max. loading of chamber: 200 kg
- Max. loading per internal: 30 kg
Textured stainless steel casing
- Dimensions: w(D) x h(E) x d(F): 1224 x 1720 x 755 mm (d +56mm door handle & +111mm Peltier element)
- Housing: rear zinc-plated steel
Electric data
- Voltage: 230 V, 50/60 Hz
- Electric load: approx. 1300W
Ambient conditions
Ambient temperature: 16 °C to 40 °C
Humidity rh: max. 70 %, non-condensing
