Volume: 161 liters
Interrior dimensions: 560W x 720H x 400D mm
Exterior dimensions: 745W x 1104H x 584D mm
Stainless steel grids (standard): 2
Max. number of grids: 8
Setting temperature range: 20℃ to 80℃
Working temperature range: at least 5 above ambient temperature to 80℃
Setting accuracy: 0.1℃
2 Pt100 sensors DIN class A in a 4-wire circuit for mutual monitoring, taking overfunctions in case of an error
ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour display.
Language setting: German, English, Spanish, French, Polish, Czech, Hungarian
Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
Function HeatBALANCE adapting the distribution of the heating performance of the upper and lower heating circuit from -50 % to +50 %
Function setpointWAIT: the process time dose not start until the set temperature is reached
Calibration: three freely selectable temperature values
Adjustable parameters: temperature (Celsius or Fahrenheit), programme time, time zones
Convection: natural convection
Programme stored in case of power failure
Programming: AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port
Ethernet interface on the rear of the appliance for reading out the protocol log and for uploading programmes and for online logging
Temperature control: mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 20°C above nominal temperature, overtemperature monitor TWW, protection class 3.1 or adjustable temperature limiter TWB, protection class 2, selectable on display
Additionally integrated over- and undertemperature monitor "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature
Autodiagnostic system: for fault analysis
Alarm: visual and acoustic
Door: fully insulated stainless steel door with 2-point locking
Structured stainless steel housing, scratch-resistant, robust and durable; rear of zinc-plated steel
Internal data logger with a storage capacity of at least 10 years
Voltage: 230 V, 50/60 Hz
Electrical load: 1600 W
Ambient temperature: 5 – 40℃
Humidity: max. 80% rh, non-condensing
