Volume: 29 liters
Interior dimension: 385W x 305H x 250D mm
Exterior dimension: 550W x 607H x 400D mm
Thermoshelf of aluminum (standard): 1
Max. number of thermoshelves (with premium module): 2
Temperature sensor: Temperature measured through 4-wire Pt100 sensor individually for each thermoshelf
Working temperature range: min. 5°C above ambient up to 200°C
Setting accuracy temperature: up to 99.9 °C: 0.1 / from 100 °C: 0.5
Setting temperature range: +20 to +200 °C
Vaccum range: 5 – 1100 mbar
Pressure control: digital electronic pressure control for a speed-controlled vacuum pump. Tubing for vacuum, air and inert gas are made of material 1.4571 (ASTM 316 Ti). Programmable, digitally controlled inlet for air.
Permitted final vacuum: 0.01 mbar
Maximum leckage rate: 0.01 bar/h
Pump control: speed control, optimised rinsing procedures for the pump membrances as well as signal output for pump ON/OFF
Connection: vacuum connection with small flange DN16, and gas inlet with small flange DN16
Adjustable parameters: temperature (Celsius or Fahrenheit), pressure (vacuum), programme time, time zones
Language setting: German, English, Spanish, French, Polish, Czech, Hungarian, Italian
ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour displays
Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
Function SetpointWAIT: the process time does not start unitil the set temperature is reached
Interface: Ethernet LAN, USB
Programme stored in case of power failure
Programming: AtmoCONTROL sofware on a USB stick for programming, managing and transfering programmes via Ethernet interface or USB port
Temperature control: mechanical temperature limiter TB, protection class according to DIN 12880 to switch off the heating approx. 100C above norminal temperature
AutoSAFETY: additionally integrated over-and undertemperature protection "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature, compressor in case of undertemperature
Alarm: visual and acoustic
Fuzzy-supported MLC (Multi-Level-Controlling) microprocessor controller adapting its performance to the volume (local temperature sensing) for each thermoshelf
Thermo shelves: 1 connection for thermoshelves in the rear
Material: hermetically welded stainless steel interior of extremely corrosion-resistant stainless steel, material 1.4404
Door: full-sight glass door, inside spring-loaded, 15 mm thick glazed panel in safety glass, outside with anti-splitter screen
Housing: rear zinc-plated steel
Ambient temperature: 5 – 40°C
Humidity: max. 80% RH, non-condensing
Voltage: 230 V, 50/60 Hz
