Dimensions: 1178 x 650 x 1973 mm / 3.9 x 2.2 x 6.5 ft
Maximum vacuum: 2124 Pa / 0.3 psi
Maximum volume flow: 790 m³/h / 208696 gal/h
Filter surface: 4.1 m² / 6355 sq.inch
Hose connection Ø: 100 mm / 4 "
Chip bag capacity: 135 l / 36 gal
Mains voltage: 220 - 240 V
Rated input power: 1.1 kW
Weight: 114 kg / 251 lbs
Noise emission
Sound pressure level: 78 dB(A)
Sound power level (LwA): 94 dB(A)
Delivery
Suction hose 100 x 2500 mm
Accessories
SAWING
Other accessories for semi-stationary/stationary saws
OTHER ACCESSORIES
Occupational safety
Datasheet
Features
Raw air extraction device, meets the purity and safety requirements of the regulation GS-HO-07
User protection by means of continuous compliance of only 0.1 mg/m³ residual dust content (dust class M)
Released for commercial use
For connection to stationary and semi-stationary woodworking machines
Optimum ratio of flow and vacuum for maximum performance
Cyclone technology goes easy on the filter for extended maintenance intervals
Manometer for monitoring the minimum air volume flow
Easy and effective filter cleaning, even during operation
Stable stand with supported chip collection bag
Wheeled collection container for easy transport of the chips
Release lever for quick changing of dust sack
Window for checking fill level of bin
Comprehensive range of accessories: automatic switch-on devices, filter cartridges, hoses and adapters
