Metrel MI 3394 End-Of-Line Safety Testing In Production (100 V – 5100 V; 500 V – 6000 V)

HV AC Programmable: 100 V – 5100 V / 10 V steps / Output power 500 VA max

HV AC Limits: Short circuit current > 200 mA / High limit current 100 mA

HV DC Programmable: 500 V – 6000 V / 50 V steps / High limit current 10 mA

Discharging time: Threshold limits 34 V, 60 V, 120 V

Earth continuity test (2W, 4W): Test currents 200 mA, 4 A, 10 A, 25 A

Insulation resistance (Riso, Riso-S): Test voltages 50 V, 100 V, 250 V, 500 V, 1000 V

Substitute leakage (Isub, Isub-S): Test voltage < 50 V a.c. (current recalculated to 110 V or 230 V)

Differential leakage: Measured @ mains voltage

Earth leakage (Ipe): Measured @ mains voltage

Touch leakage: Measured @ mains voltage

Leaks & Power: Measured @ mains voltage

Parameters: P, S, Q, PF, THDu, THDi, Cosø, I, U

Communication interfaces: RS232, USB, Ethernet, and Bluetooth

Memory: microSD card support up to 32 GB

Protection Classification: Perfectly suited for work places in accordance with EN 50191

Fuses: F1, F2 (F 3.15 A / 250 V)

Rack Integration: A 1584 19" Rack mount adapter supported
