Fall Time: 54 ns
Rise Time: 32 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 80 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 230 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 17.5 ns
Typical Turn-Off Delay Time: 55 ns
Id - Continuous Drain Current: 320 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 620 uOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 4 V
