Shutdown: No Shutdown
Topology: Dual
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 20 mg
Qualification: AEC-Q100
Amplifier Type: Linear Op Amp
Mounting Style: SMD/SMT
SR - Slew Rate: 1.1 V/us
Moisture Sensitive: Yes
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2 V
Ib - Input Bias Current: 150 pA
Operating Supply Current: 100 uA
Vcm - Common Mode Voltage: 0 V to 5.8 V
Ios - Input Offset Current: 100 fA
Output Current per Channel: 10 mA
Vos - Input Offset Voltage: 1.5 mV
GBP - Gain Bandwidth Product: 2 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.6 fA/sqrt Hz
en - Input Voltage Noise Density: 27 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 83 dB
PSRR - Power Supply Rejection Ratio: 91 dB
