Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Mounting Style: SMD/SMT
SR - Slew Rate: 20 V/us
THD plus Noise: 0.002 %
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.8 V
Ib - Input Bias Current: 200 pA
Operating Supply Current: 720 uA
Vcm - Common Mode Voltage: 5.8 V
Ios - Input Offset Current: 1 pA
Output Current per Channel: 50 mA
Vos - Input Offset Voltage: 1.6 mV
GBP - Gain Bandwidth Product: 10 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.6 fA/sqrt Hz
en - Input Voltage Noise Density: 16 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 125 dB
PSRR - Power Supply Rejection Ratio: 100 dB
