Test Force
0.098N(10gf)0.245N(25gf)0.49N(50gf)0.9807N(100gf)
1.961N(200gf)2.942N(300gf)4.903N(500gf)9.807N(1kgf)
Loading Method: Auto Loading , Dwelling, Unloading
Turret: Auto
Dwelling Time: 0~60s(every 5 seconds as one unit)
Eyepiece: 10x
Objective: 10x(observation) , 40x(measurement)
Total Magnification: 100x(observation) , 400x(measurement)
X-Y Test Anvil: Size: 100x100 mm,Travel: 25x25mm, Resolution: 0.01mm
Test Height: 90mm
Test Throat: 100mm
Net Weight: 31kg
Machine Dimension: 480x325x545mm (LxWxH)
Power Supply: AC110/220 V/50~60 Hz
Working Environment
In the range of (23±5) °C at room temperature.
Placed horizontally on a solid foundation.
No corrosive media around it in a vibration-free environment.
Indoor relative humidity is not more than 65%
Packing List：
Machine Mainframe: 1 set
Diamond Micro Vickers Indenter: 1 PC
X-Y Test Table: 1 PC
Thin Specimen Clamp: 1 PC
Hardness Block 400~500 HV0.2 :1 PC
Weights: 6 PCS
Horizontal Adjusting Screw: 4 PCS
Fuse 1A: 2 PCS
Power Cord: 1 PC
Anti-dust Cover: 1 PC
10X Digital Measuring Eyepiece: 1 PC
10X, 40X Objective: 1 PC ea.
Flat Clamp: 1 PC
Filament Clamp: 1 PC
Hardness Block 700~800 HV1: 1 PC
Weight Axis: 1 PC
Level: 1 PC
Halogen Lamp 12V, 20W: 1 PC ea.
Screwdriver: 2 PCS
Instruction Manual: 1 Copy
