MKS 228A Baratron® Differential Capacitance Manometers (10 Torr; 0-5 VDC)

Measurement Type: Differential

Full Scale Range: 10 Torr

Analog Output: 0 - 5 VDC

Calibration: Bidirectional

Fitting Type: 0.25 in. OD tube

Electrical Connector: 15-pin HD D-sub

Resolution: 0.01% of Full Scale

Accuracy: 0.50% of Full Scale

Zero Temperature Coefficient: 0.1% Full Scale/°C for standard accuracy specification

Span Temperature Coefficient: 0.04% of Reading/°C

Sensor Internal Volume: Measurement Side" 1.4 cm3, Reference Side 9.0 cm3

Operating Temperature Range: 0 - 50°C

Maximum Overpressure:

- Measurement Side: 120% of Full Scale or 20 psi (140 kPa), whichever is higher

- Reference Side: 120% of Full Scale

Maximum Line Pressure: 40 psig (275 kPa)

Exposed Materials: Measurement Side: Inconel, Reference Side: Inconel, ceramic, palladium, stainless steel, glass

Measurement Side Fitting: 0.25 in. OD tube

Reference Side Fitting: 0.25 in. OD tube

Mounting Bracket: No

Trip Points: 2

Relay Contact Ratings: DPDT, 1.0 A at 30 VDC or 0.3 amps at 120 VAC

Warm-up Time: 30 minutes

Power Requirements: ±15 VDC

Compliance: CE, SEMI S2-0706

For specific range please check the attachment below!
