Pitch: 1.27 mm
Height: 1.45 mm
Card Type: SIM
Orientation: Horizontal
Unit Weight: 243 mg
Mating Cycles: 10000 Cycles
Mounting Type: Standard
Current Rating: 500 mA
Mounting Style: PCB Mount
Number of Rows: 1 Row
Voltage Rating: 15 VDC
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: SMD/SMT
Number of Contacts: 6 Contact
Flammability Rating: UL 94 V-0
Insertion - Extraction Style: Push-Pull
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 30 C
