Dimming: Analog, PWM
Features: 10 Addresses Configurable via an External Resistor, 6-Bit Analog Dimming, 12-Bit PWM Dimming, Digital Interface, Fault Indicator, LED Current Configured via an External Resistor, LED Open Protection, LED Short Protection, Over-Temperature Protection, Refresh Signal Output, UVLO Protection
Topology: PWM
For Use With: General Displays, Instruments Clusters, LED Backlighting, LED Indicators, RGB Drivers
Mounting Style: SMD/SMT
Output Current: 80 mA
Number of Outputs: 16 Output
Number of Channels: 16 Channel
Input Voltage - Max: 16 V
Input Voltage - Min: 4.5 V
Operating Frequency: 220 Hz, 250 Hz, 280 Hz, 330 Hz, 1 MHz
Pd - Power Dissipation: 2.97 W
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
