Impulse Mode:
Voltage range in kV: 0-4 / 0 - 8 / 0 - 16
Energy (at each range) in Joules: 500
Single Impulse: YES
Selectable auto frequency per minute: 40/20/10
ARM module: NO
DC test mode: NO
Voltage in kV: NA
Current in mA: NA
Burn Current in mA 4kV: NA
Burn Current in mA 8kV: NA
Burn Current in mA 16kV: NA
Sheath test (Optional): NO
Voltage range in kV: NA
Current in mA: NA
General Parameters:
Input Power Supply: 230V AC + 10%
Power Frequency: 50Hz or 60Hz + 5%
Operating temperature: -10 ° C to + 55 ° C
IP rating: 21
Approximate Weight in KG: 60
Approximate size (L x W x H) in mm: 450 X315 X 550
Standard Accessories:
50kV High Voltage cable in meter: 5
Mains cable in meter: 5
Earth cable in meter: 5
Rexin cover: YES
