Output Voltage: DC 25kV (negative polarity)
Load: Electrostatic capacity, less than 1μF
Short-circuit Current: Approx. 2.5mA (at the time of output 25kV, no loading)
Leakage Current Setting: Less than 0.01μA (Output: 25kV, Tempeature: 25℃, Humidity: less than 70%)
Voltmeter: 25kV (1.5 class)
Ammeter: 10, 100, 1000μA by range selection (1.5 class)
Recorder Output: 1μA/10mV
Power Supply: Rechargeable Ni-Cd battery 14.4V (continuous use: 4 hours)
Battery Charging Time: Approx. 15 hours by AC 100V (in case that the battery voltage is indicated within red mark at panel meter)
Dimension: W360×H230×D175mm
Weight: 11kg
Accessory: Cable lead wires 2m & 15m, Lead wire for DC power supply 2m, Cords for precise voltmeter, ammeter and recorder
