Murata Electronics LQW15AN15NH00D Wirewound 15 NH 3%
Manufacturer: Murata Electronics Model: LQW15AN15NH00D - Contact
Width: 0.6 mm
Height: 0.5 mm
Length: 1 mm
Q Minimum: 30
Shielding: Unshielded
Tolerance: 3 %
Inductance: 15 nH
Application: Non-Magnetic
Termination: Standard
Unit Weight: 1 mg
Mounting Style: PCB Mount
Test Frequency: 100 MHz
Termination Style: SMD/SMT
Maximum DC Current: 460 mA
Maximum DC Resistance: 160 mOhms
Self Resonant Frequency: 5 GHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
