Video:
Hdmi version: hdmi 2.1 (frl5 40gbps)
Hdcp version: hdcp 2.3 and 1.4
Hdcp on/off: yes
Maximum clock rate: 600 mcsc (594 mhz)
Maximum throughput per channel: 10.0 gbits/sec (40 gbp/sec total)
Resolution timings: vesa; video standard with 60, 59.94, 30, 29.97, 24, 23.98, fps; video standard with 50, 25 fps; auto and 10 user definded
Video encoding: rgb, ycbcr
Video sampling models: rgb 4:4:4, yuv 4:4:4, yuv 4:2:2, yuv 4:2:0 hdmi 2.0
Color bit depth: 8, 10, 12, 16, and auto edid read
Patterns: over 80 built in including isf geometery, isf resolution, isf pluge, colors, focus, resolution, bars, ramps, multiburst, black/white and moving bars.
Audio:
Audio channels: up to 8 (7.1)
Audio output: 2 ch lpcm
Vu meter channels: up to 8 (7.1)
Ports:
Hdmi: type a
Audio (l/r input): 3.5mm stereo (3-conductor)
Sync (sync & latency test): 3.5mm stereo (3-conductor)
Rs232: 3.5mm stereo (3-conductor)
Firmware/control: micro usb
Environmental:
Operating temprature: 23 to 125°f (-5 to 51°c)
Storage temperature: -4 to 140°f (-20 to 60°c)
Humidity range: 5-90% rh (no condensation)
Power:
Power: 7.4v 2600ман internal battery or wall adapter
Power consumption (total): 12 watts max
Power supply
Input: ac 100-240v~50/60hz
Output: dc 12v 2a
Dimensions:
Dimensions (unit only depth/width/height)
Mm: 28.8 x 108.44 x 139
Inch: 1.13 x 4.27 x 5.47
Weight (unit): 0.8 lbs/0.36 kg
