Range: 50°C to 350°C
Resolution: 0.1°C
Accuracy: ±0.4°C
Stability: ±0.05°C
Stabilisation Time: 20 Minutes
Temperature Readout: °C / °F Switchable
Well Diameter: 25 mm
Immersion Depth: 110 mm
Heating Time (Ambient to max.): 20 Minutes approx.
Cooling Time max. (to 100°C): 33 Minutes approx.
Switch Test facility: Provided
Interchangeable Thermowells: Single hole to suit 1/4″ & 1/2″ Probes.
Housing / Mounting: Bench-top
Power Supply / Consumption: 230V AC, 50 Hz, 520 W
Instrument Dimensions (L x D x H): 160 x 365 x 350 mm
Instrument Weight (approx.): 8 Kg.
Measurement Capability
+ Thermocouples : ISA Types J, K, R, S, N
+ RTD: Pt100 IEC Std.
+ mA : 0 to 25 mA
+ mV : 0 to 100 / 1000 mV
+ Volt : 0 to 10 V
+ Resistance : 0 to 500 W / 3.5 KW
-Standard Delivery:
Basic Instrument
Test Leads
Mains Cable
Insertion Tubes (to suit 1/4“ & 1/2“ probes)
Tool for Insertion Tubes
Spare Fuses
RS-232 Computer Interface
“MTCCal” Calibration Software
Traceable Calibration Certificate
Instruction Manual
Carrying Case
-Optionals:
Additional Thermowells / Insertion Tubes (to choose from) :
+ Single hole standard sizes to suit :
1/8”, 1/4”, 3/8”, 1/2”, 3/4”, 7/8” & 3, 4, 5, 6, 7, 8, 10, 12, 13, 15, 17, 19 & 21 mm probes
+ Multihole (Typical) : (1x6 + 1x8), (3x6), (1x10 + 1x4) mm
115V AC / 60 Hz Power Supply
Calibration Certificate from NABL Accredited– as per ISO/IEC 17025:2005 Laboratory
