Maximum test force（KN）: 100
Test force accuracy: 0.5％
Test force classification: The whole process is not graded.
Constant pressure accuracy: 0.5％
Test force measurement range（KN）: 0.5%-100% of full scale
Loading speed（KN/S）: 2.4KN/S ±200N／S
Relative error of force control rate: ±0.5％
Upper platen size(mm): Φ155
Lower platen size(mm): Φ155
Upper and lower platen distance(mm): 260
Column spacing (mm): 300
Screw stroke（mm）: 100
Power supply power（kw）: 0.75
Power supply: Regular voltage 220V
Dimension（mm）: 730×600×1426
Weight of the whole machine（kg）: 300
Computer Configuration: Lenovo / HP computer
Printer Configuration: HP Printer
Software Configuration: 1 set of test software under WINDOWSXP platform in English and Chinese
