Image Sensor: 1280 × 800 CMOS
Illumination: White LED
Barcode Reading:
1D: EAN-13, EAN-8, UPC-A, UPC-E, Code 128, Code 39, Codabar, UCC/EAN 128, RSS, ITF, ITF-14, ITF6, Standard 25, Matrix 25, COOP 25, Industrial 25, Plessey, MSI Plessey, Code 11, Code 93, Code 49, Code 16K, etc.
2D: PDF417, QR Code, Data Matrix, Aztec, CSC, Maxicode, Micro QR, Micro PDF417, GM, Code One, etc.
Resolution: ≥3 mil
Depth of Field:
EAN-13: 55–360 mm (13 mil)
Code 39: 70–180 mm (5 mil)
PDF417: 55–160 mm (6.7 mil)
Data Matrix: 50–170 mm (10 mil)
QR Code: 40–210 mm (15 mil)
Minimum Print Contrast: 25%
Scan Angle: Roll: 360°; Pitch: ±55°; Skew: ±55°
Scan Modes: Sense Mode, Continuous Mode, Level Mode, Pulse Mode
Field of View: Horizontal 51°, Vertical 32°
Dimensions: 41.5 (W) × 49.5 (D) × 24.3 (H) mm
Weight: 56 g
Indicators: Beeper, LED
Rated Power Consumption: 1622 mW (typical)
Operating Voltage: 5 VDC ±5%
Aiming: 650 nm Laser Diode or 518 nm Green LED
Current @5VDC: Operating: 276.8 mA (typical), 322.7 mA (maximum); Standby: 83.3 mA
Interface: RS-232; USB
Operating Temperature: -20°C to 60°C
Storage Temperature: -40°C to 70°C
Humidity: 5%–95% (non-condensing)
ESD Protection: ±14 kV (air discharge), ±8 kV (direct discharge)
Drop Resistance: 1.5 m
Protection Rating: IP54
Certifications: FCC Part 15 Class B, CE EMC Class B, RoHS, IEC60825, IEC62471, KC
