NGI N38118-2250-25 Wide Range High Power Programmable DC Power Supply (2250V, 25A, 18kW)

Voltage: 2250V

Current: 0~25A

Power: 0~18kW

CV Mode

Range: 0~2250V

Setting Resolution: 10mV

Setting Accuracy (23±5℃): 0.05%+0.05%F.S.

Voltage Ripple (Vp-p): ≤2500mV

Voltage Ripple (rms): ≤400mV

CC Mode

Range: 0~25A

Setting Resolution: 0.1mA

Setting Accuracy (23±5℃): 0.1%+0.1%F.S.

CP Mode

Range: 0~18kW

Setting Accuracy (23±5℃): 1%F.S.

Voltage Measurement

Range: 0~2250V

Readback Resolution: 10mV

Readback Accuracy (23±5℃): 0.05%+0.05%F.S.

Current Measurement

Range: 0~25A

Readback Resolution: 0.1mA

Readback Accuracy (23±5℃): 0.1%+0.1%F.S.

Line Regulation

Voltage: ≤0.01%F.S.

Current: ≤0.05%F.S.

Load Regulation

Voltage: ≤0.02%F.S.

Current: ≤0.05%F.S.

Interface: Standard: RS232/LAN, optional: RS485/CAN/GPIB/USB

AC Input: Three phase 340VAC ~ 460VAC, frequency 47Hz ~ 63Hz

Efficiency: 93%(Typical)

Power Factor: 0.99(Typical)

Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~70℃

Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa

Net weight: Approx. 32kg

Dimension: 132.5(H)*482.0(W)with handle*711.0(D)mm, with output shield
