NGI N6909-1000-270 Single-Channel High Power DC Electronic Load (9kW, 1000V, 270A)

Voltage: 1000V

Current: 270A

Power: 9000W

Min operating voltage: 20@27A/ 20V@270A

CC mode

Range: 0~27A/ 0~270A

Setting Resolution: 1mA/ 10mA

Setting Accuracy (23±5℃): 0.05%+0.05%F.S.

CV mode

Range: 0~100V/ 0~1000V

Setting Resolution: 10mV/ 100mV

Setting Accuracy: (23±5℃) 0.05%+0.05%F.S.

CP mode

Range: 0~9000W

Setting Resolution: 0.1W

Setting Accuracy (23±5℃): 0.5%+0.5%F.S

CR mode

Range: 0.07Ω~370Ω / 1.4Ω~3703Ω

Setting Resolution: 16 bits

Setting Accuracy (23±5℃): 0.35%+8.4mS / 0.35%+0.84mS

Slew Rate

Current: 4.5~270A/ms / 270~13500A/ms

Voltage: 8~400V/ms 400~4000V/ms

Power: 4.5~270A/ms / 270~13500A/ms

Resistance: 4.5~270A/ms / 270~13500A/ms

Voltage Measurement

Range: 0~100V/ 0~1000V

Readback Accuracy (23±5℃): 0.05%+0.05%F.S.

Current Measurement

Range: 0~27A / 0~270A

Readback Accuracy (23±5℃):0.05%+0.05%F.S.

Power Measurement

Range: 0~9000W

Readback Accuracy (23±5℃): 0.5%+0.5%F.S.

Interface: LAN/RS232/CAN

AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz

Sampling Frequency: 25Hz

Communication Response Time: ≤10ms

Operating Environment: Altitude: <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa

Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃

Net weight: Approx. 81kg

Dimension: 9U, 397.5(H)*482.0(W)with handle*612.0(D)mm
