Measuring Range: ± 5.00mm/m ± 0.286°
Resolution:
0.001 mm/m (0.0001°) within ±1.999 mm/m
0.01 mm/m (0.001°) beyond ±2 mm/m
Operating Temperature: 0~40°C
Accuracy:
Operating temperature 17~23°C:
±0.85% rdg within ±1.999 mm/m
±1.0% rdg beyond ±2 mm/m
Operating temperature 0~40°C:
±2.6% rdg within ±1.999 mm/m
±2.7% rdg beyond ±2 mm/m
Repeatability: Within ±0.005 mm/m (±0.0003°)
Communication Interfaces: RS-232C port, Bluetooth Class 1 (range 30–50 m)
Power Supply:
One 9V dry battery
One 8.4V 006P rechargeable battery
9V output AC adapter
Battery Life:
Zinc-carbon battery: approx. 12 hours (approx. 3 hours wireless use)
Alkaline battery: approx. 30 hours (approx. 3 hours wireless use)
Rechargeable battery: approx. 10 hours (approx. 4 hours wireless use)
Body Material: Aluminum alloy
Base Material: Cast iron
Overall Dimensions: L158 × W61 × H107 mm
Base Dimensions: L150 × W55 mm
Weight: 2.0 kg
Standard Accessories:
9V output AC adapter
Two 8.4V 006P rechargeable batteries
Battery charger
Shock resistant aluminum case
USB receiving unit
Dedicated display software
Warranty card
User manual
