Output signals: 4...20 mA, 0...5 Vcc, 0...10 Vcc.
Non-linearity (BFSL): ≤ ± 0,25 % of the range, according to IEC 61298-2.
Non-repeatability: ≤ 0,1 % of the range, according to IEC 61298-2.
Accuracy: ≤ ± 0,5% of the range (1).
Thermal drift: between 0 and 80°C, 1% of span; 2,5% of span, max (2).
Long term drift: ≤ 0,1 % of span.
Zero and span adjustement: ± 10 % span typical.
Process fluid temperature: -25...+100 °C.
Ambient temperature: -25...+85 °C.
Stocking temperature: -30...+85 °C.
Response time: <4 ms (measuring); <150 ms (switching on).
Emission and immunity: according to EN 61326,
(group 1 - class B; industrial applications).
Vibration resistance: 20g (10...2000 Hz, according to IEC 60068-2-6).
Shock resistance: 40g (6 ms, according to IEC 60068-2-27).
Sensor: ceramic in Al2O3.
Case: in AISI 316L, vented up to 16 bar.
Protection degree: IP 65 according to IEC 60529 (3).
Process connection: in AISI 316L, hole ø 2,5 mm (with restrictor ø 0,7
mm for measuring ranges ≥ 60 bar).
Weight: 0,18 kg
