Logic Type: I2C, SMBus
Output Type: Open Drain
Unit Weight: 37 mg
Logic Family: PCA9535
Input Voltage: 5 V
ESD Protection: 2 kV
Interface Type: I2C, Serial, SMBus
Mounting Style: SMD/SMT
Number of I/Os: 16 I/O
Output Current: 50 mA
Output Voltage: 5 V
Interrupt Output: With Interrupt
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.3 V
Pd - Power Dissipation: 200 mW
Maximum Clock Frequency: 400 kHz
Operating Supply Current: 135 uA
Operating Supply Voltage: 2.3 V to 5.5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
