Height: 3.23 in
Weight: 2.45 kg
Materials: 17-4 PH Stainless Steel, Glass, Stainless Steel
Force Type: Compression
Hysteresis: ≤ ± 0.05% %*RO
Non-Linearity: ≤ ± 0.05% %*RO
Repeatability: ≤ ± 0.02% %*RO
Safe Overload: 200%*Emax
Load Cell Type: Through Hole
Outer Diameter: 3.27 in
Supply Voltage: 5 to 15 Vdc
Input Resistance: 800 ± 50 Ω
Electrical Output: 2 mV/V
Enclosure Ratings: IP68
Output Resistance: 700 ± 0.5 Ω
Calibration Option: NIST
Load Cell Capacity: 30 klbf
Zero/Balance Error: ≤ ± 1%*RO
Electrical Connection: Molex 1261 Series 6-Pin Female
Insulation Resistance: ≥ 500 MΩ
Through Hole Dimension: 1.65 in
Wiring/Connector Table: 1: (-) Excitation; 2: Not connected; 3: (-) Signal; 4: (+) Excitation; 5: Ground; 6: (+) Signal
Process Temperature, Max: 65 °C
Process Temperature, Min: -25 °C
Insulation Resistance Note: 500 MΩ @ 100 Vdc
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -55 °C
Temperature Effect on Sensitivity: ≤ ± 0.036 %*RO/°C
Temperature Effect on Zero Output: ≤ ± 0.027 %*RO/°C
