Filter: 20 to 40 microns Recommended
Weight: 15 g
Accuracy: ± 3 %
K-Factor: 12500 pulses/gal
Approvals: KTW, W270, FDA - 21 CFR 175.300
Output Detail: Max. 20 mA (Pull-up resistor required. See wiring diagram in User Manual.), Output (Hz): NPN sinking open collector
Output Signal: DC Pulse
Repeatability: <0.50%
Burst Pressure: 2900 psi Maximum
Pipe Size, Max: 6 in
Supply Current: 8 mA
Supply Voltage: 5 to 24 Vdc
Viscosity Range: 0 to 16 cSt
Electrical Output: Amplified Square Wave
Materials, Wetted: Brass, Graphite, PA12 Ferrite, PTFE
Pressure Drop Note: 10.15 psi Pressure Drop ∆p with Water Flow at 68° F (20°C)
Pressure Drop, Max: 10.15 psi
Repeatability Note: <0.50% under the same operating conditions
Media Compatibility: Liquids
Electrical Connection: Cable
Operating Pressure, Max: 360 psi
Process Connection Size: 3/8 in
Process Connection Type: BSPP Male
Volumetric Flow Rate, Max: 8 l/min
Volumetric Flow Rate, Min: 2 l/min
Operating Temperature, Max: 100 °C
Operating Temperature, Min: -20 °C
