Width: 17.7 mm
Height: 90 mm
Length: 1102 mm
Deadband: Relay status will change when proper setpoint condition exists for 100 msec
Mounting: DIN Rail 32 mm Standard or 35 mm
Approvals: CE
Isolation: 1800 Vdc
Materials: Silver-Cadium Oxide
Standards: IEC 801-2, Level 2
Input Type: RTD
Wire Gauge: 22 to 12 AWG
Overcurrent: Current: 200 mAac
Output Value: Process
Relay Output: 120 Vac @ 5A, 240 Vac @ 2A, 28 Vdc @ 5A
Output Detail: Relay Contacts 2 SPDT (2 form C) Relays 1 Relay per setpoint Current Rating: 120 Vac: 5A, 240 Vac: 2A, 28 Vdc: 5A
Output Signal: Relay
Response Time: <250 msec
Supply Voltage: 9 to 30 Vdc
Input Range Note: α= 0.00385
Number of Inputs: 1
Wire Code Option: 3- Wire
Relative Humidity: Operating: 15 to 95% (@45°C), Soak: 90% for 24 hours (@65°C)
Supply Power Note: 9 to 30 Vdc, 1.5 W typical, 2.5 W max
Supply Power Type: DC
Lead Resistance, Max: <1% of the maximum input temperature span.
Electrical Connection: Screw Terminal
Setpoint Repeatability: 0.0002
Sensor/Transmitter Power: 40% of base sensor resistance or 100Ω (whichever is less), max. per lead
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -25 °C
Operating Temperature, Max: 55 °C
Operating Temperature, Min: 0 °C
Temperature Measurement Range: RTD: -200 to 850°C
Limit Differentials (Deadbands): 1.0 to 5% of span
