Width: 6.1 mm
Height: 113 mm
Length: 115 mm
Weight: 70 g
Accuracy: ±8 µA
Mounting: DIN Rail 35 mm Standard, EN 60715
Approvals: CE, UL, RoHS
Bandwidth: 100 Hz
Isolation: Isolation Voltage (Test): 2.5 kVac ;Isolation Voltage (Working):300 Vac
Input Type: Current
Wire Gauge: 26 to 12 AWG
EMC Standard: NAMUR NE 21
Installation: Pollution degree 2 and measurement/overvoltage category II
Output Value: Process
Voltage Loss: Input to Output: 2.5 V
Output Detail: Output Loop Current Limitation:24 mA typical Output Overload: 50 mA max
Output Signal: Current
Response Time: < 5 ms
Supply Voltage: 6 to 35 Vdc
Conversion Rate: 1:1
Input Range Note: Signal Range (Input to Output):3.8 to 20.5 mA;Signal Conversion: 1:1; Functional Range: 3.5 to 23 mA ;(NAMUR NE43 compliant);Available 2-Wire Transmitter (Tx) ;Supply: 3.5 to 32.5V
Number of Inputs: 1
EMC Immunity Note: Extended EMC Immunity NAMUR NE 21, A Criterion, Burst: <±1% of span
Electrical Output: 24 mA
Enclosure Ratings: IP20
Noise Calibration: >60 dB
Power Consumption: 50 mW
Relative Humidity: 0 to 95% RH (non-condensing)
Supply Power Type: DC
Response Time Note: Response Time (0 to 90%, 100 to 10%): <5 ms
Screw Terminal Torque: 0.5 Nm
Temperature Coefficient: ≤±0.02 µA [(T-25°C) x Vsupply]
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Current Measurement Range: 4 to 20 mA
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -25 °C
Calibration Temperature, Max: 28 °C
Calibration Temperature, Min: 20 °C
Temperature Coefficient Note: Temperature Coefficient (>25°C):≤±0.02 µA [(T-25°C) x Vsupply] Temperature Coefficient (<25°C):≤±0.07 µA [(T-25°C) x Vsupply]
