CMRR: 120 dB minimum
Width: 45 mm
Height: 117 mm
Length: 122 mm
Mounting: DIN Rail 35 mm Standard
Isolation: Isolation (Full 4-Way Isolation):input 1, output 1, output 2, power;1200 VRMS minimum
Linearity: Output Linearity: ±0.1% of span
Stability: ±0.04% of span per °C
Input Type: Current
Wire Gauge: 14 AWG
Output Value: Splitter
Output Detail: (Output 1 and Output 2): 4 to 20 mA;20V compliance, 1000 Ω at 20 mA Output Zero and Span: Multi-turn zero and span potentiometers for each output channel to compensate for load and lead variations; ±15% of span adjustment range typical Output Loop Power Supplies: One for each output channel; 20 Vdc nominal, regulated, 25 mA may be selectively wired for sinking or sourcing mA output. Output Functional Test: Front buttons set each output to test level when pressed; Each test level potentiometer adjustable 0 to 100% of span
Output Ripple: Output Ripple and Noise: <10 mVRMS
Output Signal: Current
Response Time: 70 ms typical
LED Indicators: Loop Status LEDs: Variable brightness LEDs indicate I/O loop level and status; One for input, one for each output
Supply Voltage: 9 to 30 Vdc
Impedance Input: 50 Ω typical
Input Range Note: Input Loop Power Supply:15 Vdc ±10%, regulated, 25 mA;May be selectively wired for sinking or sourcing mA input;Loop Status LEDs: Variable brightness LEDs indicate I/O loop level and status; One for input, one for each output.
Number of Inputs: 1
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP40
Supply Power Note: 9 to 30 Vdc or10 to 32 Vac 50/60 Hz,6 W maximum
Supply Power Type: DC
Electrical Connection: Screw Terminal
Current Measurement Range: 4 to 20 mA
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -10 °C
