OMEGA HX200HD-RS Remote Dew Point/Temperature Transmitter (200°C (392°F), -60 ~ 40°C, 4-20mA/RS232, remote)

One Analog Output: 4-20mA

Loop Power corresponds: -60 to 40°C dew point

Maximum Operating Temperature: 200°C (392°F) (at 0% RH)

Output signal resolution: 0.03°C

Power Supply: 12 to 28Vdc, 25 mA max.

Display resolutions: 0.1°C

Dew Point: Accuracy: +/- 1.0°C from 40°C to -20°C, +/-3.0C <-20°C

Temp. Accuracy: +/- 0.5°C from 0 to 100°C, >100C +/-1°C

Mounting: Cable Length: 1 meter (except wall units)

SS Material: Probe, filter guard and fitting Fitting: ½” NPT stainless steel (included)

Pressure rating: 750psi

Dimensions of Probe: Length: 6.5” (185mm), O.D.: 0.5” (13mm)

Digital Output: Bidirectional RS-232C outputs will display RH, dew point and temperature, in the streaming command. The loop power will not function if using the RS232.

Comes complete with probe, transmittter, user’s manual and NIST calibration certificate [calibration done at -60°C (-76°F)]
